MSRP: $13,995.00
$2,995.00 Savings
Total Price: $11,000.00
Dimensions
| Overall Length | 92.7 inch (235.5 cm) |
| Overall Width | 45.5 inch (115.5 cm) |
| Wheel Base | 65.7 in (167 cm) |
| Front Wheel Track | 37.0 inch (94 cm) |
| Rear Wheel Track | 38.8 inch (98.5 cm) |
| Ground Clearance @ Diff | 4.72 inch (12 cm) |
Power
| Power | 48-Volt Lithium or Lead Acid |
| Motor Type | Reliance AC Motor |
| Horsepower (KW) | 6.7 hp (5 kW) continuous |
| Wiring | 3-gauge Cables throughout |
| DC Converter | 30 Amp Reliance Voltage Reducer for 12 Volt Power |
| Batteries QT/Type | 48v Lithium or 6 x 8V batteries |
| Key or Pedal Start | Pedal |
| Battery Charger | On-Board Charger w/3.0 m AC Cord |
| Speed Controller | 400-Amp Reliance Solid-State AC Controller |
| Drivetrain | Motor Shaft Direct Drive |
| Transaxle | Open Differential with Helical Gears |
| Gear Selection | Forward-Neutral-Reverse Rotary Style Switch |
| Rear Axle Ratio | 12.3:1 |
Body & Chassis
| Frame | Welded Steel with Hot Dipped Galvanized Protection |
| Body & Finish | Injection Molded Polypropylene |
Steering & Suspension
| Steering | Double-Ended Rack and Pinion |
| Front Suspension | MacPherson Strut |
| Rear Suspension | Mono-Leaf Springs with Hydraulic Disc Brake |
| Service Brake | Front/Rear Hydraulic Disc Brake |
| Parking Brake | Electromagnetic Park Brake |
| Dry Weight | 576 LB (260 kg) estimated for 4-Passenger |
| Curb Weight | 992 LB (450 kg) estimated for 4-Passenger |
| Vehicle Load Capacity | 800 LB (363 kg) estimated for 4-Passenger |
| Outside Clearance Circle | 22.9 Ft (7m) |
| Speed (Level Ground) | 19.5 mph |
Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
