Specifications

Explorer Package $750 value

	Paramount MT Ties on SPDR Wheels
	Premium Interior
	Black Emblems
	2" hitch with quiet connection

Premium Mushroom Trim Package $650 value

	Comfortable premium mushroom seating and convenient weather protection including a stone beige top
	DOT Windshield, the E-Z-GO premium package is the perfect complement to your vehicle.

Accessories

	Center High-Mounted Brake Light with Backup Camera
	Side Mirrors
	ELiTE 4.2 Twin Pack with World Charger

SPECS

Overall Length	*106 in (269 cm)
Overall Width	*48 in (122 cm)
Overall Height (w/ Roof)	*76 in (193 cm)
Wheel Base	*76.5 in (194 cm)
Front Wheel Track	38 in (97 cm)
Rear Wheel Track	39 in (99 cm)
Ground Clearance	*5.5 in (14 cm)

POWER

Power Source	56.7 V Max
Valve Train	N/A
Fuel System	N/A
Horsepower/kW	11.7 hp (8.7 kW)
Electrical System	48 VDC
Key/Pedal Start	Pedal
Air Cleaner, Lubrication, Cooling System, Oil Filter, Fuel Capacity	N/A
Speed Controller	235 Amp AC Controller
Drivetrain	Direct-Drive AC Induction Motor
Transaxle	*Differential with Helical Gears
Gear Selection	Dash Mounted FNR/Key Switch
Rear Axle Ratio	*17:1 (Forward)
Batteries (Qty/Type)	*ELiTE 2.2, Single 56.7V Max Lithium
Battery Charger	Light World Charger, 56.7V, 10 ft. DC Cord

PERFORMANCE

Dry Weight	*914 lb (415 kg) (without Batteries)
Curb Weight	960 lb (435 kg)
Load Capacity	800 lb (363 kg)
Outside Clearance	*12.85 ft (3.92 m)
Speed	*Up to 19 mph ± 0.5 mph (Up to 30.6 kph ± 0.8 kph)
Range	N/A

STEERING & SUSPENSION

Steering	Self-Compensating Reduction Rack and Pinion
Suspension	Leaf Springs with Hydraulic Shock Absorbers
Service Brake	*Dual Rear Wheel Mechanical Self-Adjusting Drum
Parking Brake	Automatic Electro-Magnetic (ELiTE Only)
Tires	MT Paramount, 23x10-14, Radial, Black SPDR Alloy Wheel

BODY & CHASSIS

Frame	Welded Steel with DuraShield™ Powder Coat
Body & Finish	Injection Molded TPO

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
