Specifications

Dimensions

Overall Length	*106 in (269 cm)
Overall Width	*48 in (122 cm)
Overall Height (with Roof)	*76 in (193 cm)
Wheel Base	*76.5 in (194 cm)
Front Wheel Track	38 in (97 cm)
Rear Wheel Track	39 in (99 cm)
Ground Clearance	*5.5 in (14 cm)

Power

Power Source	56.7 V Max
Horsepower/kW	11.7 hp (8.7 kW)
Electrical System	48 VDC
Key/Pedal start	Pedal
Speed Controller	235 Amp AC Controller
Drivetrain	Direct-Drive AC Induction Motor
Transaxle	*Differential with Helical Gears
Gear Selection	Dash Mounted FNR/Key Switch
Rear Axle Ratio	*17:1 (Forward)
Batteries QTY/Type	*ELiTE 2.2, Single 56.7V Max Lithium
Battery Charger	Light World Charger, 56.7V, 10 ft. DC Cord

Performance

Curb Weight	960 lb (435 kg)
Load Capacity	800 lb (363 kg)
Outside Clearance	*25.7 ft (7.83 m)
Speed	*Up to 19 mph ± 0.5 mph (Up to 30.6 kph ± 0.8 kph)

Steering & Suspension

Steering	Self-Compensating Reduction Rack and Pinion
Suspension	Leaf Springs with Hydraulic Shock Absorbers
Service Brake	*Dual Rear Wheel Mechanical Self-Adjusting Drum
Parking Brake	Automatic Electro-Magnetic (ELiTE Only)
Tires	Kruizer, 185/60-14, SBR, Machined SPDR Alloy Wheel

Body & Chassis

Frame	Welded Steel with DuraShield™ Powder Coat
Body & Finish	Injection Molded TPO

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
